Bag Counting Special Packing Unit Milk Automatic Pouch Packing Machine

Type:Multi-Function Packaging
Function:Filling, Sealing, Wrapping
Application:Chemical, Food, Medical, Coffee
Packaging Type:Bags, Zipper self-supporting bag
Packaging Material:Plastic
Automatic Grade:Automatic
Driven Type:Electric, Inflatio
Voltage:380V 3phase 50HZ/60HZ
Power:6.5KW/7.5KW/8.5KW
Place of Origin:Tianjin, China (Mainland)
Brand Name:SANQIAO
Certification:CE/ISO9001
After-sales Service Provided:Engineers available to service m
Work position:8 work position
Bag material:composite membrane
Warranty time:1year
Model Number:GD8-200(250)
Condition:New


Packaging & Delivery

Selling Units:Single item
Single package size: 180X200X320 cm
Single gross weight:1200.0 kg
Package Type:We will use wooden cases to pack the machines. For each machine, we will give free items to vulnerable parts, such as heaters.
Lead Time :
Quantity(Set) 1 - 1 >1
Est. Time(day) 45 To be negotiated


Type 200 250 300
Bag size W:100-210mm L:100-350mm W:150-260mm L:150-350mm W:200-300mm L:200-450mm
Packing speed 10-40bags/min  10-35bags/min 10-35bags/min
Power 6.5KW 7.5KW  8.5KW
Work position 8 work position 8 work position  8 work position
Bag material composite membrane composite membrane  composite membrane
Bag type Zipper self-supporting bag, self-supporting bag  Three side seal  Plane bagFour-side sealReticule Back bag,etc Zipper self-supporting bag, self-supporting bag  Three side seal  Plane bagFour-side sealReticule Back bag,etc  Zipper self-supporting bag, self-supporting bag  Three side seal  Plane bagFour-side sealReticule Back bag,etc
Voltage 380V 3phase 50HZ/60HZ(Customized)  380V 3phase 50HZ/60HZ(Customized) 380V 3phase 50HZ/60HZ(Customized)
Compressed air 260kg0.6m³/min(supply by user) 0.6m³/min(supply by user)  0.6m³/min(supply by user)
